Maiju Mechanical Equipment Co., Ltd. specialize in the production and supply of MK8 and Mini MK8 cigarette making machines for small and medium tobacco factories. With years of manufacturing experience, we provide stable, durable, and high-efficiency cigarette making equipment with complete spare parts and professional technical support.
All our cigarette machines adopt mature mechanical structure, low failure rate, easy operation and low energy consumption. Whether you need new machines, refurbished units or full accessory replacement, we can provide one-stop solutions for your tobacco production line.
Our machines are widely exported to Southeast Asia, Africa, the Middle East and other regions. We support customized production, machine renovation and overseas after-sales service.
The range of our products is as following:
1. Cigarette maker with type of Mark 8, Mark 9,. Featured in Mark 8 cigarette making machine and HLP 180 cigarette packing machine.
2. Cigarette packer with type of HLP2.
3. Filter rod maker with type of KDF2E.
GDX1 Cigarette Packing Machine
GDX1 Cigarette Packing Machine For Soft Packet
GDX1 Cigarette Packing Machine is also a medium-speed model, capable of producing 400 soft packets per minute. It was developed on the basis of X1SC/4350/PACK-OW, which technology was introduced through the Technology Transfer Agreement between G.D, and China National Tobacco Corp. It consists of an YB15 Tray Feeder, an YB25 Cigarette Soft Packer, an YB55 Cellophaner, an YB65 Cartoner and an YB95 Overwrapper.
GDX1 Cigarette Soft Packet Machine Technical Data
roduction Capacity: | 400 packets/min (40 cartons/min) |
Cigarette Specifications |
|
Diameter: | φ7.8mm |
Length: | 84mm |
Cigarette Collation: | 7-6-7 |
Packet Dimension: | 86mm ×54.5mm ×22.5mm |
Stamp Specifications |
|
Width: | 19mm ~23mm |
Length: | 42mm~50mm |
Carton Dimension: | 274mm × 87.5mm × 46.5mm |
(American and European style) | |
Noise Level: | ≤85 dB(A) |
Power: | 19.1kw |
Weight: | 9370kg |
Floor Area: | 7300mm × 7600mm |
(All the products specification can be configured upon customized requirements.) | |
GDX1 Cigarette Soft Packing Machine picture
HLP2 Cigarette Packing Machine is used to pack cigarettes into packets.(This model is also called as HLP 180 cigarette packing machine) It is a well developed technology and are widely used in the cigarette factories all over the world. According to the customer's requirements, the machine has a wide working range like packing different numbers of cigarettes into one pack, such as 10's, 12's, 16's, 20's, 25's; different cigarette diameters and lengths such as 7.8*84mm, 7.8*100mm, 6.2*84mm, 5.4*100mm, 5.4*84mm; different packet forms and shapes such as square pack, round corner pack, bevel edge pack, shell&slide pack. In one word, we make machines according to customer's specific request.
HLP2 automatic cigarette packing machine has been widely used in cigarette industry for a few decades. In 1980S, China Tobacco Monopoly imported the production technologies of HLP 2 cigarette packing line and the related patents from Europe.
The layout of HLP2 automatic cigarette packing machine is shown as below picture:
HLP2 Tobacco Packing Machinery general
HLP2 Cigarette Packing Machine consist of bellow 5 parts:
•YB43 Packer
•Stamper
•YB59 Wrapper
•YB69 Cartoner
•YB99 Overwrapper.
It consists of hinged-lid packet packer, stamper, packet film wrapper, cartoner, and carton film overwrapper, and it can automatically perform the operation of hinged-lid packet packing, stamping, packet film wrapping, carton packing and carton film overwrapping.
This packing line is mainly composed for four single machines: YB43A Cardboard Packet Packing Machine, YB59A Packet Film Packing Machine, YB69A Carton Packing Machine and YB99 Carton Film Packing Machine (Coupon Insert Unit and YTB Tax Mark Sticking Unit are optional)
HLP2 Tobacco Packing Machinery parameter
| # | 名称 Items | 参数 Parameters |
|---|---|---|
| 1 | Output Speed | 180packs／min |
| 2 | Rated efficiency | 80％ |
| 3 | Voltage | 380±10% |
| 4 | Frequency | 50Hz |
| 5 | Air Pressure | >0.6MPa |
| 6 | Air Flow | >48m3/h |
| 7 | Pressure of the Vacuum Pump | >0.05MPa |
| 8 | Air Flow from the Vacuum Pump | >60m3/h |
| 9 | Ambient Temperature | 25±5℃ |
| 10 | Relative Humidity | 55％-56％ |
| 11 | Height above sea Level | not higher than 2000m |
| 12 | Dust Content | not higher than 3mg／m3 |
| 13 | Cigarette Circumferencer | 4 24.5±0.3mm |
| 14 | Cigarette Length | 84±0.5mm |
| 15 | Way of Packets Packing | Hinged-Lid Packet |
| 16 | Collation | 7-6-7 |
| 17 | Overall Size of Packet | 87.5x56x23.5mm |
| 18 | Way Of Carton Packing | Europe Standard |
| 19 | Size of Carton | 282.5x90x48.5mm |
| 20 | Overall size of combination | 7200x6700mm |
| 21 | Total Weight of the combination | 6200kgs |
| 22 | PLC Control | |
| 23 | Equipment Color(Paint by buyer require) Normally green |
YB43 Packer,YB43A Hinge-lid Packing Machine
1) YB43 Packer, YB43A Hinge-lid Packing Machine
This product is used for hard packet carton packing of cigarettes with length of 84~100mm with different diameters, and in different arrangements (10’s in 5-5, 12’s in 6-6, 16’s in 8-8, and 20’s in 7-6-7 or 10-10 arrangements).
Features:
•It has features of slow starting, automatic protecting, automatic detecting, ejecting and failure indicating, easy operation, and convenient maintenance, which makes it and ideal cigarettes packing unit for small and medium size cigarette factory.
•Especially, with its low cost, good packing quality, and stable performance, it is suitable for special such as slim packing, long cigarette packing, round corner packing, octagonal packing, and 10’s ~ 16’s packing.
Technical Specifications:
•Capacity: 180 packs/min
•Cigarette Specification: Length: 84~100mm; Diameter: 5.4~8mm
•Packet Size: 87.5x56x23.5mm(King Size)
•Carton Size: 283x90x48.5mm(King Size)
YB59 Wrapper,YB59A Packet Film Packing Machine
YB59A Packet Film Packing Machine is used for wrapping of cigarette packets with BOPP film, so as to keep the moisture content of cigarette unchanged and cigarette flavor fresh inside the packet, A tear tape is also winded around the BOPP film for easy opening of packet.
Feature:
•Wide-range application to different cigarette packet dimensions, and widely adopted in industry field of food, medicine, cosmetics etc.
•High operation efficiency and low wastage.
•Easy operation, and convenient maintenance.
Technical Specifications:
•Capacity: 180 packs/min;
•Overall size: 2600x700x1600(including conveyor)
•Weight: 1450kg
•Power: 2.7KW
•Capacity: 180 packs/min;
•Overall size: 2600x700x1600(including conveyor)
•Weight: 1450kg
•Power: 2.7KW
YB69 Cartoner,YB69A Carton Packing Machine
YB69A Carton Packing Machine is used for packing 10 packets of cigarette in two layers (2×5) into one carton.
Features:
•Wide-range application to different cigarette packet dimensions.
•High operation efficiency and low wastage.
•Compact structure and low energy consumption.
•Easy operation, and convenient maintenance.
Technical Specifications:
•Capacity: 18 cartons/min;
•Overall size: 1950x1800x1550
•Weight: 815kg
•Power: 1.5KW
•Capacity: 18 cartons/min;
•Overall size: 1950x1800x1550
•Weight: 815kg
•Power: 1.5KW
YB99 Overwrapper,YB99 Carton Film Packing Machine
5) YB99 Overwrapper,YB99 Carton Film Packing Machine
This product is used for overwrapping of cigarette carton with BOPP film. Also it can be used for naked overwrapping of cigarette packets (soft and hard packets applicable) in two layers (2×5 for 20’s packet) or in four layers (4×5 for 10’s packet) directly with BOPP film(without carton).
This product is used for overwrapping of cigarette carton with BOPP film. Also it can be used for naked overwrapping of cigarette packets (soft and hard packets applicable) in two layers (2×5 for 20’s packet) or in four layers (4×5 for 10’s packet) directly with BOPP film(without carton).
Feature:
•Wide-range application to different cigarette packet dimensions and arrangements.
•High operation efficiency and low wastage.
•Compact structure and low energy consumption.
•Easy operation, and convenient maintenance.
Technical Specifications:
•Capacity: 18 cartons/min;
or 180 packs/min. for 20’s packet naked wrapping;
or 360 packs/min. for 10’s packet naked wrapping;
•Overall size: 2100x1100x1200
•Weight: 600kg
•Power: 1.52KW
•Capacity: 18 cartons/min;
or 180 packs/min. for 20’s packet naked wrapping;
or 360 packs/min. for 10’s packet naked wrapping;
•Overall size: 2100x1100x1200
•Weight: 600kg
•Power: 1.52KW
Stamper,YTB Tax Mark Sticking Unit
2) Stamper,YTB Tax Mark Sticking Unit
This product can automatically perform stamping of tax stamp to cigarette packet with different dimensions, such as king size packet, slim packet, long cigarette packet, round corner packet, and octagonal packet.
This product can automatically perform stamping of tax stamp to cigarette packet with different dimensions, such as king size packet, slim packet, long cigarette packet, round corner packet, and octagonal packet.
Features:
•Wide-range application to different packet dimensions.
•Automatic detecting and ejecting packets without stamp.
•High operation efficiency and low wastage.
•Easy operation, and convenient maintenance.
Technical Specifications:
•Capacity: 180 packs/min;
•Tax stamp size: 45x20mm(or as per request)
•Capacity: 180 packs/min;
•Tax stamp size: 45x20mm(or as per request)
HLP cigarette packing machine layout
Please check the following video for reference of YB43A packer which is most important part of HLP2 cigarette packingline.
Please check the following video for reference of whole line.
